Name: 120kW Rated Output Methanol Fuel Cell Generator with Zero-Emission Clean Energy and Ultra-Low Electricity Cost
Brand: JoShining Energy & Technology Co.,Ltd
SKU: X120-1
Price: 700,001.00 USD
Availability: InStock

Trang chủ > các sản phẩm > methanol Cracking >

120kW Rated Output Methanol Fuel Cell Generator with Zero-Emission Clean Energy and Ultra-Low Electricity Cost

Nguồn gốc:

Trung Quốc

Hàng hiệu:

Joshining

Chứng nhận:

Số mô hình:

X120-1

Liên hệ với chúng tôi

Yêu cầu báo giá

120kW Rated Output Methanol Fuel Cell Generator with Zero-Emission Clean Energy and Ultra-Low Electricity Cost

Chi tiết sản phẩm

Công suất đầu ra định mức:

120kW @ 380V AC

Thông số nhiên liệu:

62 ~ 63 wt% dung dịch metanol-nước, 0,66 kg metanol/kWh, dung dịch 130 kg/h

Mô-đun tế bào nhiên liệu:

Hệ thống PEMFC nhiệt độ thấp độc quyền với ngăn xếp 150kW

Mô-đun lưu trữ năng lượng:

Pin 96 kWh Niken-Kẽm (Ni-Zn) hoặc Lithium Iron Phosphate (LFP)

Hệ thống làm mát:

Trung tâm quản lý nhiệt tích hợp cao độc quyền

Kích thước môi trường:

4,1 × 2,5 × 2,8 m

Điều khoản thanh toán và vận chuyển

Số lượng đặt hàng tối thiểu

Giá bán

negotiable

chi tiết đóng gói

hộp gỗ

Thời gian giao hàng

30-60 NGÀY

Điều khoản thanh toán

L/C,T/T

Khả năng cung cấp

100

Sản phẩm liên quan

99% -99,9999% Đơn vị Cracking Hydrogen hệ Purity Methanol

Nhận giá tốt nhất

Hydrogen sản xuất Methanol Cracking hệ thống Đối với Chuông Loại lò luyện kim

Nhận giá tốt nhất

Nâng nhiệt độ áp suất cao Methanol Cracking cho khí bảo vệ trong lò

Nhận giá tốt nhất

Giải pháp khí bảo vệ Methanol Cracking Hydrogen Generator By Advanced Technology

Nhận giá tốt nhất

Liên hệ với chúng tôi

Liên hệ ngay bây giờ

Mô tả sản phẩm

High-Efficiency Methanol Fuel Cell Generator 2.5kW-120kW

Methanol Fuel Cell Generator System (FCS) represents the next generation of clean energy technology. By seamlessly integrating advanced methanol steam reforming with high-performance proton exchange membrane fuel cells (PEMFC), this system converts a methanol-water mixture directly into stable, eco-friendly electricity. Whether you need a compact backup power source or the world's largest 120kW rated output for industrial, grid-connected, or vehicular applications, this system delivers unrivaled efficiency and economic value.

Key Features & Technical Capabilities

World-Leading 120kW Rated Output: Providing the largest rated output capacity globally for methanol-to-hydrogen power generation
Ultra-Low Electricity Cost: Achieve exceptional economy with optimized electricity costs
True Zero-Emission Clean Energy: Green energy profile with absolute zero emissions of SOx, NOx, and Particulate Matter (PM)
Flexible Operational Modes: Fully capable of independent off-grid operation or seamless integration into vehicular applications and grid-connected systems
Long-Endurance Continuous Run: Equipped with a standard 1m³ (1t) fuel tank, the 120kW system can continuously power your operations for 8 hours at rated load

Core Technology Architecture & Working Principle

FCS utilizes a proprietary closed-loop system designed for maximum thermal and electrochemical efficiency.

Methanol Reforming & Hydrogen Production: A fuel mixture of methanol and demineralized water goes into the reformer, utilizing waste heat and steam to produce hydrogen efficiently
Hydrogen Purification: The generated gas passes through proprietary purification technology to deliver high-purity hydrogen
Fuel Cell Integration: The pure hydrogen combines with ambient air in the highly integrated PEMFC system to output reliable, stable electrical power

Technical Specifications & Product Parameters

Parameter / Model	Poseidon-LT-2.5	Poseidon-LT-10	Poseidon-LT-50	Poseidon-LT-100
Power Output	2.5 kW	10 kW	50 kW	100 kW
System Output Voltage	48 VDC or 220 VAC (Highly adaptable for telecom/backup)
Fuel Composition	59-61 wt.% Methanol Demineralized Water
Methanol Consumption	0.6 kg/kWh
System Efficiency	40%
System Lifespan	20,000 hours
Acoustic Noise Level	< 65 dB @ 1m (Ultra-silent operation)
Ambient Temperature	-10°C to 55°C
Dimensions & Weight	1150 * 600 * 1200 mm / Weight: 200 kg

Why Partner with Joshining?

We possess full core competencies across Hydrogen Generation Reforming, Hydrogen Purification, and Fuel Cell System Integration.

Highly Modularized Engineering: Every high-power unit integrates an advanced Hydrogen Buffer Tank, Hydrogen Generation Module, Fuel Cell Module, Energy Storage Module, and Electrical Control Module into a single robust frame for rapid plug-and-play deployment
Substantial Operational Savings: Lower your total cost of ownership (TCO) with high-efficiency output and fuel consumption optimized to the absolute physical limits
Global Export Capability: Built to comply with strict international industrial and electrical standards, making it the ideal clean energy upgrade for global markets

What are the primary emissions of this methanol-to-hydrogen system?

This is an exceptionally clean power solution. The chemical process results in zero SOx, zero NOx, and zero Particulate Matter (PM), making it ideal for environmentally sensitive regions, urban zones, or indoor industrial setups.

Get a Tailored Clean Energy Quote Today!

Looking to replace polluting diesel generators, reduce grid electricity costs, or integrate clean fuel cell power into your commercial fleet? Our engineering team is ready to customize the system to match your precise voltage and power requirements.
